Size |
Approximately 3.6 inches high, 8.2 inches long, and .55 inches deep
*The depth from the tip of the analog sticks to the tip of the ZL/ZR buttons is 1.12 inches
|
Weight |
Approx. .61 lbs
|
Screen |
Capacitive touch screen / 5.5 inch LCD / 1280×720 resolution
|
CPU/GPU |
NVIDIA Custom Tegra processor
|
Storage |
32 GB of internal storage, a portion of which is reserved for use by the system. Users can easily expand storage space using microSDHC or microSDXC cards up to 2TB (sold separately).
|
Wireless |
Wi-Fi (IEEE 802.11 a/b/g/n/ac
Bluetooth 4.1 / NFC (near field communication) |
Speakers |
Stereo
|
Buttons |
Left Stick
Right Stick
A B X Y L R ZL ZR + – Buttons
+ Control Pad
Power Button
Volume Button
HOME Button
Capture Button
|
USB connector |
USB Type-C
Used for charging only.
|
Headphone/mic jack |
3.5mm 4-pole stereo (CTIA standard)
|
Game card slot |
Nintendo Switch game cards
|
microSD card slot |
Compatible with microSD, microSDHC and microSDXC memory cards.
*Once the microSDXC card is inserted, a system update will be necessary. An Internet connection is required to perform this system update.
|
Sensor |
Accelerometer / gyroscope
|
Operating environment |
41-95 degrees F / 20-80% humidity
|
Internal battery |
Lithium ion battery / battery capacity 3570mAh
|
Battery life |
Model number: HDH-001
Approx. 3.0 to 7.0 hours
*The battery life will depend on the games you play. For instance, the battery will last approximately 4 hours for The Legend of Zelda: Breath of the Wild. |
Power Consumption |
Handheld & Tabletop modes
Playing a game: Approx. 4W
Watching a video: Approx. 3W
On the main menu: Approx. 2W
Sleep mode: Approx. 0.03W
Power off: Less than 0.01W
Estimated annual energy consumption*: Approx. 3 kWh
*The estimated annual energy consumption of a console when used for gaming an average two hours per day for a whole year.
Values have been rounded off to the nearest full value. There also may be some statistical variations on the energy consumption values displayed. The values could also change depending on the usage environment and conditions.
|
Charging time |
Approximately 3 hours
*When charging while the hardware is in sleep mode
|
